Low Power Consumption Low Heat Dissipation P4.81 Outdoor Rental Led Display
Product presentation
1. Super light - weight is only 14kg, one hand can be lifted, quick installation
2. Ultra-thin -- the box body is made of die-cast aluminum, with high strength, strong toughness, high precision and not easy to deform, which saves labor for transportation
3. High precision -- the size is accurate to 0.1mm by mechanical and electrical processing
4. Compatibility -- new structure design, meet the requirements of lifting, stacking, indoor and outdoor requirements
5. Fast -- the box body is connected up and down around the fast locking mechanism,
6. Reliable -- high strength and hardness, good heat dissipation effect
7. Cost - the box weight is light, the installation cost is low; Low power consumption, saving operating costs, reduce labor costs
Rental LED Screen Features
1, strong stability, using high-quality components and fine processing technology, effectively reduce the rate of dead light. Power signal double backup system, guarantee long time stable operation, support 7*24 hours uninterrupted work.
2, low light and high gray, brightness down to 20% can still present perfect gray performance, display consistency is very good. The grayscale performance of the display is almost perfect under low brightness, and the picture layering and brightness of the display are higher than that of the traditional display.
3, high refresh rate, HD camera shooting pictures without stripes.
4, good consistency, high strength structure fine tuning technology, realize the whole screen seamless stitching. Eliminate light and dark lines by fine tuning. Point by point correction technology, the whole screen brightness, chroma consistency and uniformity.
5, ultra wide Angle of view, LED screen body Angle of 160°, all angles of the picture is uniform, clear and natural.
6, low reflectivity using black fog lamp and corrugated light absorbing mask, in the light of the environment is small, the picture is still clearly visible.
7, high contrast, using high-quality black lamp and corrugated light absorption sub-black mask, clear and sharp image, bright color.
8, intelligent brightness adjustment, automatically adapt to photosensitive adjustment equipment, will not affect the display screen due to environmental light. There is almost no loss of gray level under 50Nits~800Nits brightness.
| Pixel Pitch | 3.91mm |
| LED Lamp | SMD1921 |
| IC | ICN2153 |
| Module Size | 250x250mm |
| Module pixels | 64x64dots |
| Cabinet Size(WxHxD)(mm) | 500x1000x88 mm |
| Module Quantity(pcs) | 8 |
| Cabinet resolution WxH | 128x256dots |
| Cabinet Material | Aluminum die casting |
| Cabinet Weight (kg) | 14 |
| Average Power/sqm (watts) | 200 |
| Max Power/sqm(watts) | 650 |
| Brightness | 4500-5000cd/㎡ |
| Viewing Angle | H:160°, V:120° |
| Best Viewing Distance | 3.91-200 meters |
| Brightness Control | 256 level |
| Gray scale | 16 bit |
| Refresh frequency | 3840hertz |
| Driving mode | 1/16 scan |
| Input power frequency | 50 or 60 Hertz |
| Input Voltage | 110 ～ 240 Volt,60Hz |
| Blind spot rate | ＜1/10000 |
| Lifetime at 50% brightness | 100000 hours |
| Ingress Protection | IP65 |
| Operating temperature | ﹣20 ～﹢60 ℃ |
| Operating humidity | 10％ ～ 90％ |
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km |
| Signal input format | HDMI,DVI,SDI,VGA etc. |
| Operating system | Windows (2000/XP/Vista/7/8/10) |
FAQ
Q1: Is the product customizable?
A: Yes,we can customize the product according to customers' needs, you just need to provide the requirements details.
Q2: Do you test all your goods before delivery?
A: Yes,we have 100% test before delivery.
Q3:What is your terms delivery?
A: EXW,FOB, CFR, CIF, DDP, DDU...
Q4: How about your warranty?
A: Different product offer different time frame warranty, but all product here we offer 2year at least warranty.
Q5: What kind of packaging you offer?
A: During the packaging process, preventive measures will be taken by us to assure that the goods are in a good condition during storage and delivery.
Q6: What project did you have done in overseas?
A: 2017, MPLED P6 outdoor led display assist for Senator Election of South Korea
2018, MPLED P10 outdoor led display light up in The World Cup in Russia
2019, MPLED P2.97 stage led display stand the stage for Senator Election of Indonesia
2020, MPLED P1.86 led display(more than 150sq.m) install in Singapore Casino
2020, MPLED P3 led display covered the SAINT PHILA CONVENTION HALL
2021, MPLED P8 outdoor customized wave led display light up in Kuwait landmark
