P3.91 Indoor Full Color LED Display Video Wall Panels SMD2121
Portable P3.91 Indoor Led Display P3 Indoor Led Display Video Wall
Product presentation
1. 500*500mm and 500*1000mm different size cabinet can well do mixture joint to make creative stage.
2. Quickly solve the power failure of the power box without disassembly.When a power failure, power cord failure or aviation plug failure occurs, the adjacent cabinets will share the output current to make the screen display normally.
3. Installation Protection ,Automatic edge protection & effective corner protection,Protect the LEDs near the edge of the cabinet, effectively reducing damage by 50% caused during installation,Ensure that the LEDs are free from contact with the ground when the cabinet is placed on the ground.
4. Precise Arc, Fast Lock,9s to replace angle block, arcing faster,From -5 °(convex) to +10°(concave), wide range of curving,creative screen shapes and sizes.
5. Intelligent and dynamic low power consumption under low brightness and gray level.
6. Automatic lock design enables one engineer to finish installation, disassembly and maintenance.
| Pixel Pitch | 3.91mm |
| LED Lamp | SMD2121 |
| IC | ICN2153 |
| Module Size | 250x250mm |
| Module pixels | 64x64dots |
| Cabinet Size(WxHxD)(mm) | 500x500x88 mm |
| Module Quantity(pcs) | 4 |
| Cabinet resolution WxH | 128x128dots |
| Cabinet Material | Aluminum die casting |
| Cabinet Weight (kg) | 7.5 |
| Average Power/sqm (watts) | 200 |
| Max Power/sqm(watts) | 650 |
| Brightness | 1200cd/㎡ |
| Viewing Angle | H:160°, V:120° |
| Best Viewing Distance | 3.91-200 meters |
| Brightness Control | 256 level |
| Gray scale | 16 bit |
| Refresh frequency | 3840hertz |
| Driving mode | 1/16 scan |
| Input power frequency | 50 or 60 Hertz |
| Input Voltage | 110 ～ 240 Volt,60Hz |
| Blind spot rate | ＜1/10000 |
| Lifetime at 50% brightness | 100000 hours |
| Ingress Protection | IP30 |
| Operating temperature | ﹣20 ～﹢60 ℃ |
| Operating humidity | 10％ ～ 90％ |
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km |
| Signal input format | HDMI,DVI,SDI,VGA etc. |
| Operating system | Windows (2000/XP/Vista/7/8/10) |
FAQ
Q: Are you manufacturer or trade company?
A: We are manufacturer,
Q: Do you offer OEM&ODM service?
A: Yes, we do.
Q: What’s the quality standard of your products?
A: Our products has approved CCC, ISO9001, CE, RoHS certification.
Q: Which place will use ITC equipment?
A: Our products are widely used in International Conferences, Governments,Banks,Churches, Highways,Airports,Parliaments,Education institutes,Hotel,Private corporate conference hall and so on.
Q: What project did you have done in overseas?
A: 2017, MPLED P6 outdoor led display assist for Senator Election of South Korea
2018, MPLED P10 outdoor led display light up in The World Cup in Russia
2019, MPLED P2.97 stage led display stand the stage for Senator Election of Indonesia
2020, MPLED P1.86 led display(more than 150sq.m) install in Singapore Casino
2020, MPLED P3 led display covered the SAINT PHILA CONVENTION HALL
2021, MPLED P8 outdoor customized wave led display light up in Kuwait landmark
